DIGISKAN Digital TV Antenna DTV-HD2
DIGISKAN Digital TV Antenna DTV-HD2 is backordered and will ship as soon as it is back in stock.
Pickup currently unavailable at Double Bay Hardware
Notify me when available or suggest replacement.
Sign up to be the first to know when it's here, or suggested replacement product.
The DIGISKAN Digital TV Antenna (DTV-HD2) is an indoor free-to-air antenna supporting Full HD 1080 reception across VHF and UHF frequency bands. Built with SMD (Surface Mount Device) technology for reliable signal preservation, it covers reception channels 5–12 and 21–69 with a maximum output level of 80 dBuV and a low noise figure of 1.8dB (VHF) / 2.3dB (UHF) for clean, interference-free picture quality. The IEC male connector and 75-ohm impedance ensure compatibility with standard Australian TV setups. Powered via AC 100–240V with a DC 5V/550mA working voltage.
Key Features
- Receives free-to-air digital TV channels
- Full HD 1080 resolution reception
- SMD technology for reliable signal preservation
- Covers VHF (47–230MHz) and UHF (470–862MHz) frequency bands
- Low noise figure: 1.8dB (VHF) / 2.3dB (UHF)
- IEC Male connector, 75-ohm impedance
- Horizontal polarisation
Specifications
- Frequency: VHF Band I/II/III 47–230MHz, UHF Band IV/V 470–862MHz
- Reception Channels: 5–12 & 21–69
- Output Level: Max 80 dBuV
- 3dB Beam Width: +22° / +22° (VHF/UHF)
- Max Noise Figure: 1.8 / 2.3dB (VHF/UHF)
- Polarisation: Horizontal
- Input Voltage: AC 100–240V
- Working Voltage: DC 5V / 550mA
- Connector: IEC Male
- Impedance: 75Ω
- SKU: DTV-HD2
-
